Միանգամյա դարակաշարերի ակտիվ ակտիվ ներդաշնակ ֆիլտր

The Single-phase Rack Mount Active Harmonic Filter (AHF) provides precise harmonic mitigation for 220V single-phase power systems. Utilising a DSP+CPLD digital control core and advanced filtering algorithms, this rack-mounted AHF effectively cancels harmonic currents up to the 50th order. Its modular design allows for flexible configurations and simplified maintenance. The 25A rated current capacity and compact 220mm x 330mm x 160mm (DWH) dimensions make it ideal for rack integration in various applications. Forced air cooling ensures reliable operation even under demanding conditions. This Single-phase Rack Mount Active Harmonic Filter guarantees power quality and stability for sensitive equipment.

Model description:

Features:

● Use DSP+CPLD all digital control core, three-level topology technology, advanced harmonic detection algorithm and PWM control strategy to achieve accurate compensation of harmonic current.
● Adopt modular design, which facilitates parallel connection of multiple modules, takes up little space and is easy to maintain.
● The structural design of independent air ducts and independent warehouses ensures the stable operation of the equipment.
● It can filter harmonics in a wide range of harmonics, from 2 to 50 harmonics, and solve the problem of three-phase unbalance at the same time.
● The harmonic filtering rate is high. If the capacity allows, the harmonic current filtering rate can be as high as 95%. Set 100% current limiting output to ensure long-term stable operation of the equipment.

Applications:

Single-phase Rack Mount Active Harmonic Filters are crucial for maintaining clean power in a range of environments:

● Data Centers and Server Rooms: Protecting sensitive IT equipment from harmonic distortion, ensuring data integrity and system uptime.
● Medical Facilities: Providing stable power for critical medical devices operating on single-phase 220V supplies, enhancing patient safety.
● Telecommunications Equipment: Minimising harmonic interference in telecommunications systems, ensuring clear and reliable communication.
● Industrial Control Systems: Improving the performance and reliability of single-phase powered industrial control systems by reducing harmonic distortion.

Single-phase Rack Mount Active Harmonic Filters offer effective and space-saving harmonic mitigation solutions for sensitive single-phase applications.

Technical Parameters:

Model& Specification:
